Wide Wavelength Range |
|
|
|
Low Power Application |
|
|
|
Broadband 105 : 1 extinction ratio |
|
|
|
Prism with size >19 mm is available on special request |
|
Wollaston prism is an optical device that separates unpolarized
light into two orthogonal, linearly polarized outgoing beams.
The device consists of two birefringent prisms cemented.
Wollaston polarizers deviate the two emerging beams by nearly
equal amount in opposite directions.
Standard Specifications
Material Grade | VIS quality grade "First" calcite |
Wavelength Range | 350-2300 nm |
Size | 10x10, 14x14, 19x19 mm |
Deviation | 10°, 20° |
Extinction Ratio | 1x10-5 |
Surface Quality | 60-40 scratch and dig |
Surface Flatness | λ/4 @ 633 nm |
Max. Power Handling | 1 W/cm2, CW |
Housing | Black Anodized Aluminum View drawings |
| |
Wollaston Polarizing Prisms
Wavelength range, nm | Side size A, mm | Deviation, deg | Ordering Code |
350-2300 | 10 | 20 | 14WLP-10-20 |
14 | 20 | 14WLP-14-20 |
19 | 20 | 14WLP-19-20 |
|
Ordering
|
|
