Home > Coatings Section > AR - Laser Line Anti-Reflection Coatings
Designed to reduce the reflectivity of a component to near-zero for specific wavelength
Coatings are provided by Ion Beam Sputtering (IBS) or Electron beam evaporation with/without Ion assistance coating techniques
Laser Line Anti-Reflection Coatings in the range 0.19 - 10.6 µm are available



Laser Line AR Coatings
Wavelength, nmResidual Reflectivity, %Coating Code
266<0.5AR1
343 - 355<0.25AR2
400<0.2AR3
473 - 488<0.2AR4
515<0.2AR5
527 - 532<0.2AR6
589<0.2AR7
633<0.2AR8
780<0.2AR9
800<0.2AR10
852<0.2AR11
946<0.2AR12
980<0.2AR13
1030<0.2AR14
1047 - 1064<0.2AR15
1122<0.2AR16
1319<0.2AR17
1550<0.2AR18


Standard Specifications
Coating Adhesion and DurabilityPer MIL-C-675A
Clear Aperture>90% of diameter
Measured Residual ReflectivityR<0.2% @ 0° AOI R<0.4% @ 45° AOI
Laser Damage Threshold>8 J/cm2 for 10 ns pulses @ 1064 nm
